Multi-Channel Device Testing
The FX100 Audio Analyzer supports automated testing of professional audio products with multiple inputs and outputs. Switcher modules may extend the FX100 Audio Analyzer for simultaneous connection to 80 input and output channels.
The system may be configured for automated sequential testing of all connected Devices Under Test (DUTs) without any additional operator activities required. Individual test parameter configurations may apply at the various test stations. The PureSound Steepness measurements detects any unwanted potentiometer noise (scratch).
- Audio quality testing
- Speaker performance control
- Simultaneous or sequential measurements
Overview
Measurement Configurations
Up to 14 input and output channels can be tested using the FX100 internal modules alone.
With up to 8 external switcher modules daisy-chained together, and each module capable of handling 10 channels, the testing capabilities of the FX100 are extended to 80 Input and Output channels.
Configuration
Test System for Multi-Channel Devices
contains
- Flexus FX100 Audio Analyzer
- IS-1002 Input Switcher
with API-Software Environment - OS-0210 Output Switcher
with API-Software Environment
optional
- PureSound™ Option
- FX100 Rack Mounting
