MeasurEye, NTi Audio’s free cloud platform, now supports the complete Vibration Mode for the 5GV Vibration Monitor. Structural damage assessment and occupant comfort monitoring are both fully supported, covering 8 and 6 international standards, respectively.
Why monitor vibration?
Vibration from construction, industry and transport puts three things at risk: the structures nearby, the people who occupy them, and the sensitive equipment they may contain. The 5GV Vibration Monitor is built as one instrument for all three.
Prevent permanent damage to buildings, bridges and infrastructure caused by construction work and mechanical loads.
Keep vibration below the limits set by national and international standards.
Protect precision machines, medical devices and research equipment from vibration damage and early failure.
This makes the 5GV Vibration Monitor a fit for construction and civil engineering (pile driving, blasting and heavy machinery next to existing buildings), manufacturing and industrial sites (vibration from heavy plant, for risk management and legal compliance), and transportation infrastructure (vibration from railways, roads and metro lines reaching nearby structures).
What’s new in MeasurEye?
This release gives the 5GV Vibration Monitor full standards coverage in MeasurEye for these three application pillars.
Structural damage assessment: 8 standards supported
- DIN 4150-3 · Germany
PPV / DF
- BS 5228-2 · United Kingdom
PCPV
- SBR-A · Netherlands
PPV / DF
- ÖNORM S 9020 · Austria
PVS
- RI8507 / OSM · United States
PPV / DF
- SNCF IN1226 · France
PPV / DF
- Circular 23 July 1986 · France
PPV / DF
- Custom · user-defined
PPV / DF
Occupant comfort: 6 standards supported
- DIN 4150-2:2025-08 · Germany
KBFTi · KBFmax · KBFTm
- DIN 4150-2:1999 · Germany
KBFTi · KBFmax · KBFTm
- BS 6472-1 · United Kingdom
VDV
- Real Decreto · Spain
AWm_x · AWm_y · AWm_z · L_AW
- UNI 9614 · Italy
AWm_x · AWm_y · AWm_z
- 1/3-octave spectrum · multiple
Velocity · acceleration · dBV
Sensitive equipment
- 1/3-octave spectrum · multiple
Velocity · acceleration · dBV
Longer field autonomy with the new rechargeable battery base
The 5GV Vibration Monitor set: device, rechargeable battery base, mounting bracket, USB cable, antennas and carry bag.
The 5GV Vibration Monitor (article 600 070 001) now ships with a rechargeable battery base built around 12x Nitecore NL1840HP 18650 Li-ion cells (4000 mAh each), for a total capacity of 48,000 mAh / 173 Wh.
Battery life ranges from 20 days in Occupant Comfort mode, with a 1-second logging interval and web publication, to 100 days in Structural Damage mode, with logging and data publication every 15 minutes and power-saving mode enabled. Publishing event data only extends battery life to more than six months.
This is particularly practical for long-term, unattended monitoring on construction and infrastructure sites, where returning to swap batteries isn’t always convenient.
New accessory: Ground Mounting Plate
Ground Mounting Plate (article 600 070 016) with interchangeable spike and rounded feet, and an integrated bubble level.
Simply setting a vibration sensor loosely on soft ground or paved surfaces creates contact resonances that distort your spectral data with artificial peaks. The Ground Mounting Plate (Art. No. 600 070 016) solves this by providing a force-locked connection strictly compliant with DIN 45669-2.
Equipped with interchangeable hardened steel spikes (for poking through indoor soft carpets and floor coverings to contact the solid floor below) and rounded feet (for concrete, masonry, asphalt, or paving slabs on ground sand beds), this accessory allows field teams to seamlessly adapt to any site condition in seconds.
Full technical specifications for the 5GV Vibration Monitor are available here.
